KEY FEATURES
-
Comprehensive Safeguarding:
Incorporates advanced protective measures against open circuits, short circuits, overloads, and excessive temperatures, ensuring unparalleled safety for your LED lighting systems.
-
Incorporated Active PFC Functionality:
Seamlessly integrates a built-in active Power Factor Correction (PFC) function, enhancing energy efficiency and optimizing the power factor for improved performance.
-
Versatile Installation on Combustible Surfaces, e.g., Wood:
The adaptable design facilitates secure installation on combustible surfaces like wood, providing flexibility in your setup and peace of mind.
-
Efficient Cooling via Free Air Convection:
Optimal performance and an extended lifespan are achieved through effective cooling by free air convection, ensuring the power supply functions at its best.
-
Adherence to European Standards and Certifications:
Meets the highest European standards and holds pertinent certifications, guaranteeing quality and strict adherence to industry regulations.
-
Engineered for Unwavering Reliability:
Meticulously designed for reliability, our LED power supply series consistently delivers peak performance, minimizing downtime and ensuring a trustworthy lighting solution.
-
Tailored for LED Lighting Applications:
Specifically crafted for applications in LED lighting, our power supply series is optimized for use in the furniture and advertising industry, providing custom solutions for your unique needs.
-
Extended 5-Year Warranty for Your Peace of Mind:
Enjoy the assurance of an extended 5-year warranty, demonstrating our unwavering commitment to the durability and superior performance of our LED power supply series.
TECH SPEC
| OUTPUT | |
|---|---|
| Turn on time | < 500 ms |
| Output voltage | 24V |
| Output voltage tolerance | ±5% |
| Current range | 0-4.17 A |
| Output voltage wave | 240 mV (Vp-p) |
| Rated power | 100 W |
| Efficiency | ≥ 90% |
| INPUT | |
|---|---|
| Input voltage | 200-240V AC |
| Input frequency | 50/60Hz |
| Input current | < 1 A |
| Input power | < 120 W |
| No load power consumption | < 0.5 W (average) |
| Inrush current | < 60 A (peak) |
| Power factor | ≥ 0.9 |
| ENVIRONMENT | |
|---|---|
| Working temperature | -20 ÷ +45°C |
| Working humidity | 45%-85%, RH non-condensing |
| Max. case temp. | +90°C |
| MTBF | ~30 000 hr |
| SAFETY STANDARDS / PROTECTION | |
|---|---|
| LVD 2014/35/EU | EN 61347-1:2015-09, EN 61347-2-13:2015-04 |
| EMC 2014/30/EU | EN 61000-3-3:2013-10/A1:2019-10, EN IEC 61000-3-2:2019-04, EN 55032:2015-09/A11:2020-07, EN 55035:2017-09 |
| RoHS III 2015/863 | EN IEC 63000:2019-01 |
| Protection | open circuit / short circuit / over load / over temperature / auto recovery |
| LOGISTIC DATA | |
|---|---|
| Quantity per box | 50 pcs |
| Gross weight (1 pc) | 0.2 kg |
| Gross weight (box) | 11.6 kg |
| OTHER | |
|---|---|
| Casing material | Plastic |
| Insulation type | Class 2 |
| IP grade | IP20 |
| Input terminal size | 2 × 1 mm² (maximum wire dimension) |
| Output terminal size | 2 × 1 mm² (maximum wire dimension) |
| Output cables length | max. 2 m |
| Dimensions (L x W x H) | 320.6 x 30 x 18.2 mm |
| Warranty | 5 years |
