KEY FEATURES
-
Comprehensive Protection:
Equipped with safeguards against short circuits, overvoltage, overload, and over-temperature, ensuring the utmost protection for your LED lighting systems.
-
Embedded Active Power Factor Correction (PFC):
Features an embedded active PFC function, ensuring efficient utilization of electrical power and maintaining a high power factor for optimal functionality.
-
Durable Metal Housing with IP67 Rating:
Housed in a robust metal casing with an IP67 rating, our power supply series is built to withstand challenging environments, offering durability and longevity.
-
Mountable on Flammable Surfaces, e.g., Wood:
The versatile design allows safe mounting on flammable surfaces like wood, providing flexibility in installation.
-
Efficient Cooling by Free Air Convection:
Cooling through free air convection enhances performance and extends the lifespan of the power supply, ensuring optimal functionality.
-
Compliance with European Standards and Certificates:
Meets the highest European standards and holds relevant certifications, ensuring quality and adherence to industry regulations.
-
High Reliability:
Engineered for reliability, our LED power supply series delivers consistent performance, minimizing downtime and ensuring a dependable lighting solution.
-
Dedicated to LED Lighting Applications:
Specifically tailored for applications in LED lighting, our power supply series is optimized for use in the furniture and advertising industry, providing tailored solutions for your needs.
-
Unrivaled 5-Year Warranty for Your Confidence:
Delight in an unparalleled 5-year warranty, demonstrating our unwavering assurance in the enduring quality and performance of our LED power supply series.
TECH SPEC
| OUTPUT | |
|---|---|
| Turn on time | < 500 ms |
| Output voltage | 24V DC |
| Output voltage tolerance | ±5% |
| Rated current | 1.875 A |
| Output voltage wave | < 300 mV (Vp-p) |
| Rated power | 45 W |
| Efficiency | ≥ 84% |
| INPUT | |
|---|---|
| Input voltage | 200-240V AC |
| Input frequency | 50/60Hz |
| Input current | < 0.3 A |
| No load power consumption | < 0.3 W (average) |
| Inrush current | < 46 A (230V AC) |
| Power factor | > 0.95 |
| ENVIRONMENT | |
|---|---|
| Working temperature | -25 ÷ +50°C |
| Working humidity | 10%-95%, RH non-condensing |
| Max. case temp. | +80°C |
| MTBF | ~50 000 hr (MIL-HDBK-217F | +25°C |
| SAFETY STANDARDS / PROTECTION | |
|---|---|
| LVD 2014/35/EU | EN 61347-1:2015-09, EN 61347-2-13:2015-04 |
| EMC 2014/30/EU | EN 61000-3-3:2013-10/A1:2019-10, EN IEC 61000-3-2:2019-04, EN 61547:2009, EN 55015:2013+A1 |
| RoHS III 2015/863 | EN IEC 63000:2019-01 |
| Vibration | 10-500Hz, 1 mm, 15 minutes (for X, Y, Z each axis) |
| Protection | open circuit / short circuit / over load / over temperature |
| LOGISTIC DATA | |
|---|---|
| Quantity per box | 50 pcs |
| Gross weight (1 pc) | 0.32 kg |
| Gross weight (box) | 17.4 kg |
| OTHER | |
|---|---|
| Casing material | Metal |
| Insulation type | Class 2 |
| IP grade | IP67 |
| Input wire dimension | H05RN-F, 2 × 1 mm² |
| Output terminal size | 60245 IEC 57 (YZW), 2 × 1 mm² |
| Cables length | 2 x 170 mm |
| Dimensions (L x W x H) | 239 x 35 x 20 mm |
| Warranty | 5 years |
